Image Sensor
|
SONY CMOS IMX291 super wide dynamic CMOS Sensor
|
|
Expose mode
|
SONY CMOS IMX291 super wide dynamic CMOS Sensor
|
|
Maximum Resolution
|
Rolling shutter
|
|
Sensor Optical Format
|
1920 x 1080(2,073,600 pixels)
|
|
Pixel Size
|
1/2.8'' (6.058mm(H) x 4.415mm(V))
|
|
Dynamic Range
|
2.9μm x 2.9μm
|
|
SNRmax
|
128dB
|
|
Spectral Charactristics
|
30dB
|
|
Spectral Charactristics
|
380-650nm
|
|
Exposure Capability
|
Real-time auto, Single auto, Manual adjustment
|
|
White Balance
|
Real-time auto, Single auto, Manual adjust R G B seperately
|
|
HDMI Output Resolution
|
1920X1080P60，1920X1080P50，1920X1080P30，1920X1080P25，1920X1080I60，
1920X1080I50，1280X720P60，1280X720P50，640X480P60
(Auto adjust according to displayer)
|
|
Record format
|
Snapshot
Picture Format：JPG
Resolution：1920x1080
Record
Video Format：MOV
Resolution：1920X1080P30,1280x720P120,1280x720P60
|
|
Record Route
|
TF card(Maximum support 128G,support hot plug)
|
|
Camera Interface
|
C mount thread（1＂×1/32）
|
|
Wired picture interface
|
HDMI TYPE C Mini HDMI
|
|
Charger interface
|
Micro USB，DC5.0V (Maximum current 1A)
|
|
Displayer
|
Recommend 16:9 , at least 1080P HD displayer
|
|
Operating Temperature
|
0℃- 40℃
|
|
Storage Temperature
|
-20℃-60℃
|
|
Operating Humidity
|
30-60%RH
|
|
Storage Humidity
|
10-80%RH
|
