Sensor Model
|
NA
|
|
Scan Mode
|
Progressive
|
|
Max. Resolution
|
1600 x 1200 (Approx. 2,000,000 Pixels)
|
|
Sensor Size
|
1/3.2“ (4.73mm(H) x 3.52mm(V), Diagonal 5.90mm)
|
|
Pixel Size
|
2.8μm x 2.8μm
|
|
Sensitivity
|
1.0v/lux-sec(550nm)
|
|
DynamicRange
|
71dB
|
|
A/D Converter
|
10-bit, 8-Bit R.G.B to PC
|
|
SN Ratio
|
42.3dB
|
|
Spectral Range
|
400-650nm (with IR-filter)
|
|
Frame Size and Rate
|
5fps @1600 x 1200, 7.5fps @1280 x 1024, 1280 x 960, 20fps @800 x 600, 30fps @ Other Resolutions
|
|
Exposure
|
Electronic Rolling Snap(ERS), Auto
|
|
Color Rendering Technique
|
NA
|
|
White Balance
|
Auto
|
|
Capture/Control API
|
DirectShow, Twain, VFW
|
|
Capture Mode
|
Still Picture and Video
|
|
Software Environment
|
|
Operating System
|
WindowsXP / Vista / 7 / 8(32 & 64 bit)
|
|
PC Requirements
|
CPU: Equal to Intel Core2 2.8GHz or Higher
|
|
Memory:2GB or More
|
|
USBPort:USB2.0 High-speed Port
|
|
Operating Environment
|
|
Operating Temperature
|
-30~70°C
|
|
Storage Temperature
|
-40~85°C
|
|
Operating Humidity
|
30~80%RH
|
|
Storage Humidity
|
10~60%RH
|
|
Power Supply
|
Over USB Port
|
