Optical System
|
Finite
Optical System
|
●
|
|
|
|
|
Viewing Head
|
Seidentopf
Binocular Viewing Head, Inclined at 30º Interpupillary 48mm-75mm，1/2.5”CMOS,Active5.0Mega，Resolution2592 x 1944，USB2.0
|
●
|
|
|
|
|
Eyepiece
|
Wide
Field Eyepiece WF10X/20mm
|
●
|
|
|
Wide
Field Eyepiece WF16X/15mm
|
○
|
|
|
Wide
Field Eyepiece WF20X/12mm
|
○
|
|
|
Objective
|
Finite
195 Series Achromatic Objectives 4X 10X 40Xs 100Xs(oil)
|
●
|
|
|
|
|
Finite Plan Achromatic
Objectives CF 4X 10X 40Xs 100Xs(oil)
|
○
|
|
|
Nosepiece
|
Quadruple
Nosepiece
|
●
|
|
|
Quintuple
Nosepiece
|
○
|
|
|
Condenser
|
Abbe
Condenser NA1.25 with Diaphragm，Filter
|
●
|
|
|
|
|
Focusing
System
|
Coaxial
Coarse and Fine Adjustment, Fine Division 0.001mm, Coarse
Stroke37.7mm/Rotation, Fine Stroke 0.1mm/Rotation, Moving range 24mm
|
●
|
|
|
|
|
Stage
|
Double
Layer Mechanical Stage 142x132mm , , Moving Range75mmx50mm
|
●
|
|
|
|
|
Illumination
|
3W/LEDAdjustment
|
●
|
|
