Optical System
|
Infinite
Optical System
|
●
|
|
Viewing Head
|
Seidentopf
Binocular Viewing Head, Inclined at 30º Interpupillary 48mm-75mm，1/2.5”CMOS,Active5.0Mega，Resolution2592 x 1944，USB2.0
|
●
|
|
Eyepiece
|
Wide
Field Eyepiece WF10X/F.N.22mm
|
○
|
|
Wide
Field Eyepiece WF20X/F.N.12mm
|
○
|
|
Nosepiece
|
Backward
Quadruple Nosepiece
|
●
|
|
Backward
Quintuple Nosepiece
|
○
|
|
Objective
|
Infinite High Contrast
Chromatic-free Full Plan Objectives 4X 10X 40X 100X
|
●
|
|
Condenser
|
NA1.25
|
●
|
|
Focusing System
|
Coaxial Coarse and Fine Adjustment,
Fine Division 0.001mm, Coarse Stroke37.7mm/Rotation, Fine Stroke
0.1mm/Rotation, Moving range 24mm
|
●
|
|
Stage
|
Double Layer Mechanical Stage
216x150mm , Graphite Surface, Moving Range75mmx55mm
|
●
|
|
Kohler Illumination
|
External Illumination, 3W/LED
|
●
|
