Optical System
|
finite Optical System
|
|
magnification
|
40x-1000x.(40x-1600x optional)
|
|
Head
|
30° Inclined, 360° Rotatable
|
|
Nosepiece
|
Backward quadruple nosepiece
|
|
Stage
|
Double Layers Mechanical Stage 126×115mm, Moving Range
76×50mm, Fine Division0.1mm
|
|
Focusing System
|
Coaxial Coarse And Fine Adjustment, Fine Division0.002mm,
Coarse Stroke 37.7mm/Rotation, Moving Range 28mm,With Safty Stop
|
|
Illumination
|
3W LED lighting, predetermined center, continuous brightness
adjustable.
|
|
Condenser
|
Abbe Condenser NA1.25 with Aperture Diaphragm
|
|
Power Supply
|
External Power Adaptor, Wide Voltage AC 100~240V, DC 5V/2A
|
|
Filter
|
Blue filter Φ 38
|
|
Package Size
|
Packing Box240*214*365mm
|
|
gross weight
|
4.3KG
|
|
Eyepiece
|
large field of viewBinocular,Interpupillary Distance 50-75mm
|
|
Field
|
WF10X/18mm
|
|
objective lens
|
finite Achromatic Objective
|
|
Magnification
|
4X
|
10X
|
40X
|
100X(oil)
|
|
Condenser NA
|
0.1
|
0.25
|
0.65
|
1.25
|
|
Distance(mm)
|
18.3
|
11
|
3.8
|
1.35
|
1. Size: 7 inch
2. Weight: 0.5 kg
3. CCD pixels:1024*600 . 1/2.86 inch
4. Pixel size: 2.75*2.75 um
5.LCD screen: HD 1080P
6. Frame rate: 60FPS
7. White balance: manual, automatic
8. Brightness: Automatic / Manual
9. Color: R/G/B adjustable
10.OSD: UI design, mouse control
11. Edge enhancement: YES
12.Photo/Video: YES
13. Cross cursor: adjustable
14. Image comparison: YES

|
