Body
|
Compensation Binocular Viewing Body,
Inclined 30º,Interpupillary Adjustable Distance: 55-75mm
|
|
Eyepiece
|
WF10X(Viewing Field Diameter: ø18mm)
|
|
Achromatic objective
|
4X、10X、40X(S)、100X(S)oil
|
|
Stage
|
Size:160mm×130mm，Moving Range :76mm×50mm Vernier :
0.1mm
|
|
Nosepiece
|
Nosepiece of four holes revolving on
ball
|
|
Condenser
|
Abbe Condenser:N.A.1.25，Elevating Range:15mm
|
|
Focusing
|
Coaxial Coarse And Fine Focusing
Adjustment,Focusing Range:10mm Division of Fine Focus Adjustment:0.002mm
|
|
Illumination
|
3W LED light （had a life span of 30 thousand hours）With Adjustable Brightness，Free Voltage :100V-240V.
|
|
Screen
|
8inches 4:3 TFT-LCD screen
|
|
Image chip
|
SONY 1/3"CMOS ，Image display format: 2 mega-pixel
|
|
Image pixel
|
1600 × 1200
|
|
Frame Rate
|
15（FPS）
|
|
Legibility
|
maximum; 800 line (horizontal）
|
|
Digital interface
|
High speed USB2.O data transmission， (1600*1200、800*600) drive-free， connected to PC，Digital image taking pictures,
storing, recording .
|
|
AV interface
|
CVBS Analog video output, （PAL/NTSC）Signal System, connected to TV
|
|
Operating system
|
Windows
|
