Viewing Head

Compensation Free Bioncular Head Inclined at 30º ,360ºRotatable

●

Eyepiece

WF10X

●

WF16X

○

Objective

Achromatic Objectives 4X 10X 40Xs 100Xs(oil)

●

Condenser

Abbe NA=1.25 with Iris Diaphragm&Filter

●

Focusing System

Coaxial Coarse and Fine Adjustment, Focusing Range 30mm,Focusing Interval 0.002mm

●

Stage

Double Layer Mechanical Stage 120x125mm

●

Illumination

LED(1W) Lamp 220V or 110V

●

LED 3W lamp optional,Halogen bulb 6V/20W optional

○

Product size

37x23x47cm

●

Gross Weight

5kg

●
