Viewing Head
|
Monocular Head,Inclined at 45º ,360ºRotatable
|
●
|
|
|
|
Eyepiece
|
WF10X
|
●
|
|
WF16X
|
○
|
|
Objective
|
Achromatic
Objectives 4X 10X 40Xs 100Xs(oil)
|
●
|
|
|
Condenser
|
Abbe NA=1.25 with Iris Diaphragm&Filter
|
●
|
|
|
Focusing System
|
Coaxial Coarse and Fine Adjustment, Focusing Range 30mm,Focusing
Interval 0.002mm
|
●
|
|
|
Stage
|
Double Layer Mechanical Stage 120x125mm
|
●
|
|
|
Illumination
|
LED(1W) Lamp 220V or 110V
|
●
|
|
LED 3W lamp optional,Halogen bulb 6V/20W optional
|
○
|
|
Product size
|
37x23x47cm
|
●
|
|
Gross Weight
|
5kg
|
●
|
|
