Optical System
|
Infinite Optical System
|
●
|
|
Viewing
Head
|
Seidentopf Binocular Viewing
Head, Inclined at 30º，Interpupillary
48mm-75mm
|
●
|
|
Eyepiece
|
Wide Field Eyepiece WF10X/F.N.22MM
|
●
|
|
Wide
Field Eyepiece WF20X/F.N.12mm
|
○
|
|
Nosepiece
|
Backward
Quadruple Nosepiece
|
●
|
|
Backward
Quintuple Nosepiece
|
○
|
|
Objective
|
Infinite High Contrast
Chromatic-free Full Plan Objectives 4X 10X 40X 100X
|
●
|
|
Condenser
|
NA1.25
|
●
|
|
Focusing System
|
Coaxial Coarse and Fine Adjustment,
Fine Division 0.001mm, Coarse Stroke37.7mm/Rotation, Fine Stroke
0.1mm/Rotation, Moving range 24mm
|
●
|
|
Stage
|
Double Layer Mechanical Stage
216x150mm , Graphite Surface, Moving Range75mmx55mm
|
●
|
|
Kohler Illumination
|
External Illumination, 3W/LED
|
●
|
