1、Objective (The bottom of the culture vessels :1.5mm thick )
2 、The plain achromatic eyepiece :
3、The magnification of auxiliary objective :1.25X 4、 Total magnification =objevtive magnification X eyepiece magnification X auxiliaty objective magnification
12.5X
4X
10X
25X
40X
10X
50X
125X
312X
500X
16X
80X
200X
500X
800X
7、Range of fine shifting up and down of the adjustmint : 30mm Reading of the graduation :0.002mm 8、Shifting stage :0.1mm Reading of the graduation :190 X 145 mm² Area (length X width ) : 50 X 75 mm² 9、Range of shifting up and down of the illuminator : 20mm . 10、Built – in transformer : 240V (or 120V )/0 ~12V 11、Buld : halogen lamp 12V/50W 12、Filter : light yellow Light green 13、 Overall dimension (length X width X high ) 450 X 190 X 500 mm² Weight : 13 kg
|
