Optical System
|
finite Optical System 160mm
|
●
|
|
Viewing Head
|
Seidentopf Trinocular Viewing Head, Inclined at 30º,Interpupillary 48mm-75mm
|
●
|
|
|
Eyepiece
|
Wide Field Eyepiece WF10X/18mm
|
●
|
|
Wide Field Eyepiece WF16X/13mm
|
○
|
|
Wide Field Eyepiece WF20X/11mm
|
○
|
|
Objective
|
Finite 195 Series Achromatic Objectives 4X 10X 40Xs 100Xs(oil)
|
●
|
|
|
Nosepiece
|
Forward Quadruple Nosepiece
|
●
|
|
Forward Quintuple Nosepiece
|
○
|
|
Condenser
|
Abbe Condenser NA1.25 with Diaphragm
|
●
|
|
|
Focusing System
|
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke36mm
|
●
|
|
|
Stage
|
Double Layer Mechanical Stage 142x132mm , , Moving Range75mmx50mm
|
●
|
|
|
Illumination
|
External Illumination, 3W/LED
|
●
|
|
Optional Accessory
|
Seidentopf Trinocular Viewing Head
|
○
|
|
C Mount 0.5X
|
○
|
|
6V 20W Halogm Lamp
|
○
|
|
Product single size
|
30x20x38cm
|
●
|
|
